L-5210
High-performance I/O rich Whitebox Solutions™ uCPE appliance for cloud and data-center applications.
- Intel® 7th Gen Core™ i7/i5/i3
- DDR4 at 2400MHz, Max 128GB
- 4x NIC Module Slots ( 2 x PCIE*4 and 2 x PCIE*8)
- 4x 288-pin DIMM DDR4 at 2400MHz, Max 128GB
- 2x 2.5″ HDD/SSD Drive Bays
- 1x PCI-E*4/8 FH/HL
- 4x Cooling Fans
- Redundant PSU
Disclaimer
The price shown is in USD, limited to North America. For all other regions, please contact your sales representative.
Want more configurations options?
Call for assistance 855-852-6637 (Toll Free)
NCA-5210 has reached its End-of-Life (EOL) status, meaning that we will no longer be manufacturing or selling this particular product. However, we'll keep the webpage available on our site for your reference, existing installations, or support needs, ensuring continuous access to essential information.
High-performance I/O rich Whitebox Solutions™ uCPE appliance is specifically designed for cloud and data-center applications.
Specifications
| Platform | |
| CPU | Intel® Core™ i7/i5/i3 or Xeon® E3-1200v5/v6 or Pentium® or Celeron® (Skylake/Kaby Lake) |
| Chipset | Intel® C236 |
| BIOS | AMI SPI Flash BIOS |
| Memory Technology | DDR4 2400MHz ECC(By CPU) or non-ECC UDIMM |
| Memory Capacity | 128 GB |
| Memory Socket | 4x 288-pin DIMM |
| Storage | |
| SATA storage | 2 x 2.5” Bays |
| I/O | |
| Ethernet controller | Intel i350-AM4 |
| Default LAN | 4 NIC Module Slots |
| Console | 1 x RJ45 |
| USB 2.0 | 2 x Type A |
| IPMI via OPMA slot | Yes |
| TPM | Yes (Optional) |
| Power and Mechanical | |
| Power input | AC 90V~264V @47~63Hz |
| Type/Watt | 300W 1+1 ATX Redundant PSUs |
| Expansion | 1 x PCI-E*4/8 FH/HL |
| Processor cooling | Passive CPU Heatsink |
| System cooling | 4 x Cooling Fans with Smart Fan |
| OS and Certifications | |
| Operating System | Linux Kernel 2.6 or above, Windows 7 Pro, Windows 8 |
| Certifications | RoHS, CE/FCC Class A, UL |
| Physical and Environmental | |
| Storage temperature | -20°C to 70°C |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 5% to 95% (non-condensing) |
| Dimensions (W x H x D) | 438 mm x 44 mm x 525 mm (17.24″ x 1.73″ x 20.67″) |
| Weight | 15 kg (33 lbs) |
| LCD module | 2 x 20 Character LCM, 4 x Keypads |
| Watchdog | Yes |
| Internal RTC | Yes |
Order Information
| Model Number Key | |||||||||
| L-5210C | -c | -mm | -ss | -xxx | -xxx | -xxx | -cc | -ww | -pc |
| Product name | CPU core count | Memory | SSD | I/O interface | I/O interface | I/O interface | Cellular | WiFi | Power cord |
| Parts | ||
| Type | Designator | Available Capacity or Option |
| CPU | C | = 2/4 |
| Memory GB | mm | = 8/16/32/64/128 |
| SSD | ss | = 32/64/128/256/512GB and 1TB |
| I/O Interface | xxx | = 8GC/8GF/4XF/8XF/2QF25 / 2QF/2QF100 / 4GC/4GF (use “AD” for LTE / WIFI adaptor: no ports) |
| Cellular | cc | = C1/C2/C3/C4/C5/C6 |
| WIFI | ww | = W1/W2/W3/W4/W5 |
| Accessories | x | = TPM 1.2 /TPM 2.0 |
| Power cord | pc | = EU (Europe) /US (USA) /UK (United Kingdom) |
| Celluar Module | |
| Celluar Module | Designator |
| LTE M.2 NA/EU CAT6 | C1 |
| LTE M.2 APAC CAT6 | C2 |
| LTE mPCIe NA/EU CAT6 | C3 |
| LTE mPCIe APAC CAT6 | C4 |
| LTE M.2 Global Cat6 | C5 |
| LTE M.2 China Cat6 | C6 |
| WiFi Module | |
| WiFi Module | Designator |
| 2×2 Dual Band + BT | W1 |
| 2×2 Dual Band | W2 |
| 4×4 Dual Band Select | W3 |
| 4×4 2.4G | W4 |
| 4×4 5G | W5 |
